118
13-1-2. Recording Video and Key Signals Simultaneously
Assume a video signal is assigned to AUX1 and its key signal to AUX2.
If you need to record an input signal such as IN01, assign the signal to an AUX bus before
recording.
Let's record AUX1 video and AUX 2 key signals simultaneously to clips through STILL 2.
(1) Open the [STILL] menu PAGE 1.
(2) Turn F2 to select CLIP under STILL2.
STILL :STILL1 :STILL2 :STILL3 :STILL4 : 1/6
STORE : >FRAME: >CLIP : >FRAME: >FRAME:
(3) Go to PAGE 2. Select AUX1 and AUX2 for FILL SOURCE and KEY SOURCE
respectively.
STILL :FIL SRC:KEY SRC: 2/6
SIGNAL : =AUX1 : =AUX2 :
(4) Press F4 while holding down F3 to begin recording.
(5) Press F2 (STOP) or F4 (PAUSE) to stop recording.
Loop Recording
Loop recording automatically loops back to the memory start point when it reaches the end of
the memory and continues recording overwriting clip frames, until STOP is pressed. If LOOP
is set to ON, both playback and recording are changed to Loop mode.
LOOP can be set to ON on PAGE 6 of the [STILL] menu as shown below.
STILL :SELECT : LOOP :REC MOD:CLEAR : 6/6
CLIP : =STL1 : =ON : =STD : >OFF : F=60
Recording Mode
Two modes are available for recording. The recording mode can be set under REC MODE on
PAGE 6 of the [STILL] menu.
STILL :SELECT : LOOP :REC MOD:CLEAR : 6/6
CLIP : =STL2 : =OFF : =STD : >OFF : F=60
Mode Description
STD (STANDARD)
Standard mode.
In this mode, to start recording, press F4 (PLAY) while holding down
F3 (REC) on PAGE 5.
DRCT (DIRECT)
Direct mode.
In this mode, to begin recording, press F3 (REC) on PAGE 5.
To Next Page
