 Ex. 2
Switcher's System Format: 720/50p
To Output the AUX1 video (at 1280 x 720 resolution):
OUTPUT : XPT :FORMAT : FRQ :MV HQ : 3/4
HDMI OUT: =AUX1 : =HDTV : =--- : =--- :
 Ex. 3
Switcher's System Format: SD PAL (625/50)
To Output the MV1 SVGA video at 50Hz:
OUTPUT : XPT :FORMAT : FRQ :MV HQ : 3/4
HDMI OUT: =MV1 : =SVGA : =50Hz : =--- :
6-5-2. HD Multiviewer Video Output in SD Mode
The HDMI port can output a multiviewer video (MV1 or MV2) in HD resolution when the
switcher is running in SD mode.
(1) Displays the [SETUP - OUTPUT - OUT XPT] menu PAGE 3.
(3) Turn F2 to select HDTV.
(4) Turn F4 to select MV1 or MV2 under MV HQ and press F4 to confirm the setting.
OUTPUT : XPT :FORMAT : FRQ :MV HQ : 3/4
HDMI OUT: =--- : =HDTV : =--- : =MV1 :
Once MV1 or MV2 is selected for MV HQ, the HDMI connection does not output a video
selected under XPT but a multiviewer video selected under MV HQ. In addition, the multiviewer
signals cannot be assigned to outputs other than the HDMI.
