15
1. Prior to Starting
1-1. Welcome
Congratulations! By purchasing HVS-390 series Hanabi Switcher you have entered the world of
FOR-A and it's many innovative products. Thank you for your patronage and we hope you will
turn to FOR-A products again and again to satisfy your video and audio needs.
FOR-A provides a wide range of products, from basic support units to complex system
controllers, which have been increasingly joined by products for computer video based systems.
Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing
service to you.
1-2. Features
The HVS-390HS video switcher come in 1M/E or 2M/E configuration.
This switcher is more powerful and easier to use, while maintaining all of the highly acclaimed
functionality of the HVS-300 series.
<Standard features>
Compact HD/SD switcher main unit (3U high)
1 M/E standard, expandable to 2 M/E with HVS-39EXTME
3 types of control panels
HVS-391OU: 1 M/E Control Panel
HVS-392OU: 2 M/E Control Panel
HVS-392ROU: 2 M/E Control Panel (for rack mount use)
Two control panels (HVS-30OU/RU) for HVS-300HS are also available.
HD/SD-SDI 16-input/8-output and an HDMI output, Max. 24-input/13-output
Variety of I/O options such as HD/SD-SDI, analog/digital RGB (VGA, DVI-D), HD/SD analog
component, analog composite
Frame synchronizer on each input and up-resize engine on IN13 to IN16 (standard), which
enables both HD and SD inputs.
Built-in multiviewer output: 2 channels, supporting 4, 10 or 16-way split views with title, tally
and audio meter display
4 keys on each M/E (Chroma Key available on 2 of 4 keys). 2.5D DVE on each key channel
More than 150 of various 2D and 3D DVE transition patterns
10 sequence memories (max. 60 steps for each)
Transition effects available when loading events and switching AUX signals
4-channel still memory and 4- channel clip memory
Safety area markers
Internal color-bar generator
<Optional features>
Input/output options
HVS-30HSDI / HSDI-A / HSAI / PCIN
HVS-30HSDO / HSAO / PCO
HVS-39ED: Editor Interface software
HVS-30TALR: Tally Relay Output card
HVS-39PSM: Redundant Power Supply Unit for Main Unit
HVS-39PSO: Redundant Power Supply Unit for Operation Unit
HVS-39MEM:Clip Memory Expansion Card
HVS-39MB: Still and Clip data backup memory option
