41
5. Video Sources
5-1. How to Assign User Names to Sources
Video inputs, Still1-4 and StillKey1-4 can be assigned user-specific names, to make them easier
to identify for operators. User names can be given to input signals, internally generated black
mattes and matte signals, and still pictures. Follow the procedure below to name a signal
source.
(1) Press MENU in the CONTROL block above the numeric keypad and then press SETUP to
display the SETUP menu top page.
(2) Turn F1 to select INPUT. Then press F1 or the page down button to display the [SETUP -
INPUT] menu.
(3) Turn F1 to select RENAME. Press F1 or the page down button to display the [SETUP -
INPUT - RENAME] menu.
SETUP :>SIGNAL >PROC AMP>RENAME >ASSIGN
INPUT :>CC >COLORBAR
(4) Turn F1 to select a signal under SELECT. (See the table below.)
INPUT :SELECT :SHORT : LONG NAME (MV) : 1/1
RENAME : =IN04 : =IN04 : =INPUT04 :
SELECT
SHORT
default setting
LONG NAME
default setting (*1)
Signal description
BLACK BLAK BLACK Black signal
IN01 to IN16 IN01 to IN16 INPUT01 to INPUT16
SDI video input to rear
connectors 1-16
STILL1 to
STILL4
STL1 to STL4 STILL1 to STILL4 Still images 1 to 4
STILK1 to
STILK4
STKY1 to
STKY4
STILLKEY1 to STILLKEY4 Still KEYOUT
MATT1 to 2 MAT1 to MAT2 MATTE1 to MATTE2 BUS matte color 1 and 2
CLBAR CLBR COLOR BAR Color bar
INA1 to INA4
INB1 to INB4
IN17 to IN24
(*2)
INPUT17 to INPUT24
(*2)
Optional video inputs
on Slot A and B
(See section 2-3.)
M/E (*3) M/E M/E1 M/E1PGM re-entry
(*1) Long names are used for titles displayed on the multiviewer screen.
(*2) IN09 and following inputs are determined by the type and number of the installed input expansion card.
(*3) Only available on M/E2 if HVS-39EXTME is installed.
(5) To change the short name of a signal, use F2 to assign a name up to 4 characters in length,
entering the characters one by one. First, press F2 to highlight a character. When the latter is
highlighted, turn F2 to change it. Alphanumeric characters and symbols (ASCII characters)
can be used for names.
(6) To change the long name of a signal, use F3 to assign a name up to 8 characters in length,
entering the characters one by one. First, press F3 to highlight a character. When the latter is
highlighted, turn F3 to change it. Alphanumeric characters and symbols (ASCII characters)
can be used for names.
