213
27-3-1. Linking Titles in the System by Receiving TSL messages
The switcher can accept video titles with video signals from a router and display them on the
control panel in accordance with crosspoint switches on the router using TSL protocol. To do
this, in addition to the router control connection, another serial connection for TSL protocol is
needed.
To configure title links, connect a router to an RS-422 port (from 1 to 6) on the HVS-390HS
using an RS-422 cable. Then configure the RS-422 port as in the procedure below. Refer to
your router's User Manual for how to set up the router.
Assigning TSL to the RS-422 port
(1) Display the [SETUP - SYSTEM - RS-422] menu.
(2) Select TSLRx for the RS-422 port used for TSL connection to the router.
(3) To configure the port, set PARITY to EVEN, and BAUD (baudrate) to 38400. (The
settings may vary depending on routers.)
SYSTEM :SELECT : FUNC : BAUD :PARITY : 1/1
RS-422 : =PORT2: =TSLRx: =38400: =EVEN :
(4) Reboot the switcher after settings are complete. (See section 23-1. "Rebooting System.")
Setting Title Links
(1) Display the [SETUP - EXT I/F - ROUTER] (6/6) menu.
(2) Turn F1 to select TSL, and then press F1.
(3) Turn F2 to select the type of names on the switcher linked to the video titles on the router:
SHORT, LONG or BOTH.
(4) To link video and display addresses, turn F3 to select a video and then turn F4 to select
an address from 1 to 127 or OFF (not linked). The links should be set for each video.
EXT I/F : LINK : CHARA :SELECT :DISPLAY: 6/6
ROUTER : =TSL : =SHORT: =IN01 : =1 :
27-3-2. TSL Tally by Sending TSL messages
A TSL tally connection in the system can be configured in the same way as described for the
MFR series. See section 26-3. "Linking Titles by Sending TSL messages." To set up external
devices, see their manual pages.
