21-6. Ancillary Data
The switcher allows users to pass, substitute or blank the ancillary data in the Program (Clean)
and Preview video. Ancillary data in the current video stream is once cleared, then the same or
different data inserted. The switcher can also be set to pass or blank the ancillary data in the
AUX outputs. The ancillary data operation is set in the [SETUP - OUTPUT - ANCI] menu.
Ancillary data does not pass through all outputs as factory default setting.
Ancillary data in input video cannot be passed through if FS (input frame synchronizer) is
set to ON or RESIZE is enabled. To pass ancillary data, input the video synchronized with
the genlock signal and set FS to OFF. Note
that ancillary data in SD inputs cannot be used
when the switcher operates in HD mode.
21-6-1. M/E Outputs
Program (Clean) Outputs
(1) Open the [SETUP - OUTPUT - ANCI] menu PAGE 1.
(2) Turn F1 to select an M/E.
To Blank the Ancillary Data Space
Set PGM SWAP to OFF (default).
OUTPUT :SELECT : PGM SWAP :PREV SW: 1/2
ANCI SWP: =M/E1 : =OFF Lv=50 : =OFF :
To Pass Through Ancillary Data
Set PGM SWAP to EACH. The Lv (level) item selects the point at which the new data is to be
inserted, from 0-100. Setting Lv to 50 passes ancillary data through from the halfway point of
the background transition.
OUTPUT :SELECT : PGM SWAP :PREV SW: 1/2
ANCI SWP: =M/E1 : =EACH Lv=50 : =OFF :
To Replace Data with Ancillary Data in an AUX output
Ancillary data in program outputs can be replaced with ancillary data in AUX outputs.
To change data in the M/E1 background to that in AUX1, set the menu as shown below. (The
ancillary data will be replaced from the halfway point of the transition.)
OUTPUT :SELECT : PGM SWAP :PREV SW: 1/2
ANCI SWP: =M/E1 : =AUX1 Lv=50 : =OFF :
Preview Outputs
Ancillary data for the M/E preview output can be processed in the same way as that for
program outputs. Set PREV SW to OFF, EACH, or AUX1 to AUX8.
The ancillary data for M/E2 outputs are set in the same way as for M/E1 outputs on PAGE 2 in
the [SETUP - OUTPUT - ANCI] menu.
OUTPUT :SELECT : PGM SWAP :PREV SW: 1/2
ANCI SWP: =M/E1 : =AUX1 Lv=50 : =OFF :
