FOR-A HVS-390HS User Manual

64
7-1-2. Selecting Video Sources for AUX Outputs
(1) Press the desired AUX button in the Bus Select section. The button will light up.
(2) Press a desired button on the KEY/AUX bus.
Example 1) To Select IN1 for AUX1
Press AUX1. Then press 1 (IN01) on the KEY/AUX.
Example 2) To Select PREV for AUX2
Press AUX2. Then press PREV on the KEY/AUX.
See section 10. "KEY" for how to select key signals.
7-2. Button Switching Mode in the M/E bus
Users can change the button switching mode for the M/E bus from P/P (PGM/PST) to A/B. In
P/P mode (default), the source selections in the PGM and PST buses are switched when
transitions occur and users can always select the next background signal from the PST bus (the
bottom row). In A/B mode, the source selections in the PGM and PST buses do not switch when
transitions occur and the next signal selection must be done in the different bus after each
transition.
To Change the Switching Mode to A/B:
(1) Press MENU in the CONTROL block, then press SETUP to display the SETUP menu top
page.Turn F1 to select PANEL. Press F1 or the page down button to display the [SETUP -
PANEL] menu.
(2) Turn F1 to select TRS CTRL.Press F1 or the page down button to display the [SETUP -
PANEL - M/E1 CTRL] or [SETUP - PANEL - M/E2 CTRL] menu.
(3) Turn F1 to select A/B. Press F1 or ENTER in Keypad to confirm the setting.
PANEL :BUSTYPE:ON AIR : FADER OFFSET : 1/1
M/E CTRL: =A/B : =GRN :U=1.00 L=1.00 :
To Change the M/E Bus Indication Color:
The M/E bus indication color can be changed from green to red. (Available only when
HVS-390HS has two M/E banks and the OU controls M/E1.) Select GRN under ON AIR and
press ENTER in Keypad.
PANEL :BUSTYPE:ON AIR : FADER OFFSET : 1/1
M/E CTRL: =A/B : =RED :U=1.00 L=1.00 :
7-3. Setting-up and using the SHIFT Function
On the HVS-391OU, users can select a video signal from 20 sources, because each bus row
has 20 buttons. On the M/E bus, the SHIFT function can also be assigned to a bus button in the
same way video sources can. The SHIFT button allows users to select a video signal among 38
sources on the HVS-391OU. (The SHIFT button is also available in the KEY/AUX bus.) The
SHIFT function is not assigned to a button by default. To use the SHIFT function, assign it to a
bus button as shown in the procedure below.
P GM PREV CLEAN MV1
201918171615141312111098
KEY/AUX
AUX
87654321432
KEYER
1
1 2 3 4 5 6 7
MV2
