FOR-A HVS-390HS User Manual

48
If you want to adjust the selected color or set the color by entering its HSL values, turn F1,
F2 and F3 to enter these values or press F1, F2 and F3, enter a value from the Keypad
then press ENTER (from the keypad). Users can also set these three parameters via the
JOYSTICK block. (See section 4-2-4. "Changing Settings or Values Using the Joystick.")
Parameter Setting Range Description Joystick operation
S(Saturation) 0.0 to 100.0 Adjusts color saturation.
Moves Joystick horizontally
(X -axis)
L (Luminance) 0.0 to 100.0 Adjusts color luminance.
Moves Joystick vertically
(Y -axis)
H (Hue) 0.0 to 359.5 Adjusts color hue.
Twists Joystick cw or ccw.
(Z -axis)
5-10-2. Setting the Gradient Matte
(1) Press MENU in the CONTROL block, then press MATT to display the [BUS MATT 2
COLOR] (2/4) menu.
(2) To select a start color for the gradadient matte, turn F4 to select a color or enter the HSL
values to specify the color.
MATT2 : BUS MATT2 COLOR1 :RECALL : 2/4
COLOR1 :S=50.0 L=80.2 H=125.5: >GREEN:
(3) Press the page down button to go to the [MATT 2 COLOR2] (3/4) menu.
(4) To select an end color for the gradient matte, turn F4 to select a color or enter the HSL
values to specify the color.
MATT2 : BUS MATT2 COLOR2 :RECALL : 3/4
COLOR2 :S=50.0 L=80.2 H=125.5: >GREEN:
(5) Press the page down button to go to the [BUS MATT 2 GMAT] (4/4) menu.
(6) Turn F1 to select a pattern for the gradation matte. Set the position at POS and adjust the
softness gradient at SOFT.
MATT2 :PATTERN : POS : SOFT : 4/4
GMAT : =H : =0 : =0 :
PATTERN setting Description
COLOR1
Displays the matte color set at BUS MATT2 COLOR1.
H Displays a horizontal gradient from COLOR1 to COLOR2.
V Displays a vertical gradient from COLOR1 to COLOR2.
H/V Displays a diagonal gradient from COLOR1 to COLOR2.
