6-8-2. Creating Signal Link Groups
(1) Press the page down button to go to the [AUX LINK - LINK GRP] menu.
FUNCTION:SELECT:MASTER: SLAVE SEL/AUX : 3/3
LINK GRP: =1 : =IN01:1=IN02 2=IN03 3=IN04
Available Signals
BLK, IN01 to IN24, STL1 to STL4, STK1 to STK4,
CB, MAT1, MAT2, M/E
(If AUX1-8 is selected for the
MASTER or SLAVE bus)
M1PG, M1PV, M1CL, M1KY,
(M2PG, M2PV, M2CL, M2KY) MV1, MV2
* Signals in parentheses are available if an HVS-39EXTME is installed.
(2) Turn F1 to select an AUX LINK group to be set in the LINK GROUP menu.
(3) Turn F2 to select a signal to be set for MASTER
(4) To set the SLAVE output signals (up to three) that link to the MASTER output signal, press
F3 and then turn F3 to select a signal for Slave 1. Press F3 and then turn F3 to select a
signal for Slave 2. Select a signal for Slave 3 in the same way.
NOTE
The same MASTER output signal cannot be selected twice. SLAVE output signals can
be selected multiple times.
6-8-3. Enabling AUX LINK
(1) Display the [SETUP - FUNCTION - AUX LINK] menu.
(2) Turn F1 to set ENABLE to ON. This activates all AUX LINK groups.
FUNCTION:ENABLE : : 1/3
AUX LINK: =ON : :
Operation examples:
Assume that the AUX output link groups and their signal link groups were set as shown
below.
:SELECT:MASTER: SLAVE SEL/AUX : 2/3
AUX GRP : =1 : =AUX1 :1=AUX2 2=AUX3 3=AUX4
: =2 : =AUX7 :1=AUX8 2=OFF 3=OFF
: =3 : =M2PG :1=M2K1 2=M2K2 3=OFF
: =4 : =M1-A :1=M1-B 2=OFF 3=OFF
: =5 : =M1PG :1=M1K3 2=M1K4 3=OFF
: =6 : =OFF :1=OFF 2=OFF 3=OFF
: =7 : =OFF :1=OFF 2=OFF 3=OFF
:SELECT:MASTER: SLAVE SEL/AUX : 3/3
LINK GRP: =1 : =IN01 :1=IN02 2=IN03 3=IN04
: =2 : =M1PG :1=M1PV 2=OFF 3=OFF
: =3 : =IN05 :1=STL1 2=STL2 3=OFF
: =4 : =IN06 :1=IN07 2=OFF 3=OFF
: =5 : =IN10 :1=IN11 2=IN12 3=OFF
: =6 : =--- :1=--- 2=--- 3=---
: =7 : =--- :1=--- 2=--- 3=---
