27
3. Connection
3-1. Basic Configuration
NOTE
See section 30-1. "ARCNET" for connecting between the main unit and control
panel(s) via Arcnet. See section 21-3. "Selecting Reference Signal
"
for reference
signal setting. See section 6-3. "Preview Set Up" for how to display the preview image.
HD/SD SDI (M/E2 PGM)
HD/SD SDI (M/E1 PGM)
TSG (Reference)
VIDEO SERVER
VCR, etc.
75
Ω
termination
Reference
HD/SD SDI
75
Ω
termination
Reference
RATING LABEL
CON TROL T O MU GPI/ T ALLY OUT
(SER VI CE)
AC100-240V 50/60Hz IN
POWER 1
POWER
ON
OFF
POWER 2
ARCNET (BNC)
Preview
(AUX1)
To AC
power
source
To AC
power
source
