FOR-A HVS-390HS User Manual

43
 To Disable M/E Bank Operation
Users can inhibit M/E Bank operation by setting M/E to OFF under CONTROL on PAGE 2. All
operations including bus signal selections and transitions cannot be performed on the disabled
M/E bank.
INPUT :CONTROL: :INHIBIT: 2/6
OU ASSGN:M/E=OFF: : =ENABL:
Note that KEY ON AIR and KEY AUTO buttons for KEY3 and KEY4, however, are still active on
the disabled M/E, if KEY3 and KEY4 are displayed on AUX outputs (AUX1-8).
5-3. How to Display Signal Names on the Bus Section
Information displayed above bus buttons on each M/E can be set on the menu.
(1) Open [SETUP - INPUT - ASSIGN] menu PAGE 3.
(2) Turn F1 to select a bus button.
(3) Turn F2 to select a display type. (See the table below.)
(4) Setting INV to ON changes tests or images to reverse video.
INPUT :BUTTON : TYPE : INV : : 2/5
BUS DISP: =01 : =SHORT: =OFF : :
Submenu Parameter Setting range Description
BUS DISP
BUTTON
1 to 20,
sft1 to sft20
Selects a bus button.
TYPE
OFF Displays nothing.
SHORT Displays short signal names (up to 4 characters).
LONG Displays long signal names (up to 8 characters).
BMP Displays bitmap images.
INV
OFF Displays text or images in normal video.
ON Displays text or images in reverse video.
5-4. How to Select an M/E (HVS-39EXTME)
The HVS-390HS can expand its system from 1 M/E (mix/effects) to 2 M/E by installing an
optional HVS-39EXTME card. Once the HVS-39EXTME is installed, the user can select an M/E
to be controlled on the HVS-391OU and use a 2 M/E control panel such as HVS-392OU.
The procedure explains how to select an M/E on the HVS-391OU.
(1) Open the [SETUP - INPUT - ASSIGN] menu PAGE 6.
(2) Turn F1 to select OU.
(3) Turn F4 to select an M/E to be controlled. The defaut setting is M/E1.
INPUT :SELECT : SHIFT : LINK :CONTROL: 6/6
ASSIGN : =OU : =NORML: =--- : =M/E1 :
