Upon Receipt
Unpacking
The Hanabi Series switchers and their accessories are fully inspected and adjusted prior to
shipment. Operation can be performed immediately upon completing all required connections
and operational settings.
Check your received items against the packing lists below. Check to ensure no damage has
occurred during shipment. If damage has occurred, or items are missing, inform your supplier
immediately.
HVS-390HS Box
ITEM QTY REMARKS
HVS-390HS 1 Main unit
AC Cord 1 set Retaining clips included
Rack Mount Brackets 1 set EIA standard type
Options
HVS-30HSDI-A 1-2 HS/SD SDI 4-Input Expansion Card (Max. 2 cards)
HVS-30HSDI 1-2 HS/SD SDI 4-Input Expansion Card (Max. 2 cards)
HVS-30HSDO 1-2 HS/SD SDI 3-Output Expansion Card (Max. 2 cards)
HVS-30HSAI 1-2 HS/SD Analog 2-Input Expansion Card (Max. 2 cards)
HVS-30HSAO 1-2 HS/SD Analog 2-Output Expansion Card (Max. 2 cards)
HVS-30PCIN 1-2 Digital/Analog RGB 2-Input Expansion Card (Max. 2 cards)
HVS-30PCO 1-2
Digital/Analog RGB 2-Output Expansion Card
(Max. 2 cards)
HVS-30TALR 1-2
Tally Output Expansion Card (Relay type, Max. 2 cards),
37-pin D-sub connector (1 set, for cable fabrication)
HVS-39EXTME 1 M/E Expansion Card for upgrading from 1 M/E to 2 M/E.
HVS-39MEM 1 Clip Memory Expansion Card
HVS-39ED 1 Editor control option (software option)
HVS-39VR 1 Virtual Link software (See "HVS-39VR Operation Manual")
HVS-39PSM 1 Redundant Power Supply Unit for HVS-390HS
HVS-39MB 1 Still and Clip data backup memory option.
* Up to 2 input cards of HVS-30HSDI-A / HSD I /HSAI / PCIN can be installed.
* Up to 2 output cards of HVS-30HSDO / HSAO / PCO can be installed.
HVS-391OU Box
ITEM QTY REMARKS
HVS-391OU 1 Operation Unit (1 M/E, 20-button type)
HVS-39PSO 1 Redundant Power Supply Unit (Option)
Control Cable 1 BNC cable for ARCNET connection (10 m)
AC Cord 1 set Power cord with retaining clips
Rack Mount Brackets 1 set Optional
Operation Manual 1 (This manual)
