If HVS-30HSAO is installed:
System format Channel FORMAT setting ASPECT setting
HD
Ch1 HD Component -----
Ch2
HD Component -----
SD Component,
Composite *
4:3, SQUEEZE,
LETTER
SD
Ch1,
Ch2
Component *
(SMPTE or BetaCam level),
Composite *
-----
* You can choose whether to add 7.5% Setup to the output signals if the switcher is running in 59.94 Hz
mode. If 7.5% Setup is added to a signal, the symbol "+" follows immediately after the name of the
signal.
If HVS-30PCO is installed:
System format Channel FORMAT setting ASPECT setting
1080i
Ch1,
Ch2
1280x1024 (SXGA), 1600x1200 (UXGA) 4:3, LETTER
1680x1050 (WSXGA), 1920x1200 (WUXGA),
1920x1080 (HDTV) *
-----
720p
Ch1,
Ch2
1280x1024 (SXGA) 4:3, LETTER
1280x768 (WXGA) -----
SD
Ch1,
Ch2
800x600 (SVGA) -----
* You can choose between 60 Hz and 50 Hz for the output frequency for DVI-D (Ch 1) if the switcher is
running in 50 Hz mode (1080/50i, 720/50p or 625/50). See step (5) below.
* You cannot output video signals from the PCO outputs if the switcher is running in 1080/23.98PsF or
1080/24PsF format.
(5) Select the output frequency for HVS-30PCO between 60Hz and 50Hz in the [SETUP -
OUTPUT - OPTION] (2/2) menu. The setting can be made for each channel by turning menu
controls. The setting is available only when the switcher is running in 50Hz mode.
OUTPUT : HVS-30PCO V SCAN FREQUENCY : 2/2
OPTION :E1=60Hz E2(60Hz)F1=60Hz F2(60Hz):
