133
Detailed Data Selection for Saving Events
Data saved to the event can be selected under the [EVENT MEMORY] menu or [EVENT
STORE] menu as shown below.
[EVENT MEMORY] menu
Item Setting Description
*RATE OFF, 1 to 999 See section 16-2-3. "Transitions Using Event Recall."
AUX BUS ON, OFF
Setting to ON stores all AUX bus data. To set the AUX
bus data individually, set in the [EVENT STORE] menu.
*KEY ASG ON, OFF
Setting to ON stores the output bus where KEY3 and
KEY4 images appear. (See section 10-9. Where KEY3
and KEY4 Appear.")
*SEQ RCL ON, OFF Setting to ON stores the current sequence data.
M/E BUS ALL, M/E1, M/E2 Selects an M/E (or ALL) whose data is to be stored.
*CG WIPE ON, OFF Setting to ON stores the current CG WIPE data.
* Indicates the same item in both [EVENT MEMORY] and [EVENT STORE] menus.
EVENT : PAGE :DIRECT :PAGECLR: RATE : 1/3
MEMORY : =0 : =OFF : =CRNT : =OFF : L=0
EVENT :AUX BUS:KEY ASG:SEQ RCL:M/E BUS: 2/3
MEMORY : =OFF : =OFF : =OFF : =ALL : L=0
EVENT :CG WIPE: : 3/3
MEMORY : =OFF : : L=0
[EVENT STORE] menu
Item Setting Description
SELECT ALL
ME1BG,
ME1K1 to ME1K4
ME2BG
ME2K1 to ME2K4
Select ALL or a bus under SELECT.
Setting DATA to ON stores all data for the bus (including
signal selection, transition rate, transition type settings,
etc.).
Setting XPT to ON stores only the signal selection data.
Normally set to ON for XPT and DATA, so that
information for all buses is saved to events.
Set DATA to OFF if any data for the bus is not needed.
The data can be further selected when recalling events.
XPT ON, OFF
DATA ON, OFF
*RATE OFF, 1 to 999 See section 16-2-3. "Transitions Using Event Recall."
AUX SEL AUX1 to AUX8 Select an AUX bus at AUX SEL.
Setting AUX RCL to ON stores the information for the
bus.
AUX RCL ON, OFF
*KEY ASG ON, OFF
Setting to ON stores the output bus where KEY3 and
KEY4 images appear. (See section 10-9. Where KEY3
and KEY4 Appear.")
*SEQ RCL ON, OFF Setting to ON stores the current sequence data.
*CG WIPE ON, OFF Setting to ON stores the current CG WIPE data.
* Indicates the same item in both [EVENT MEMORY] and [EVENT STORE] menus.
EVENT :SELECT :XPT :DATA : RATE : 1/3
STORE : =ALL : =ON : =ON : =0 :P.00
To Next Page
