4. 3. 2 Analog Voltage to Image Corona
The standard value of the voltage outputted from the HV Power Supply PCB to the Image Corona
is 1.30 +/-0.05V.
Check and adjust the output current in the following way.
1. Connect the “+” cable of the multi-meter to the “CP11” pin on the HV Power Supply PCB
(EUK1MGA60HA).
Also connect the “-” one to the “CPCOM”.
And then, select the DC volt range on the multi-meter.
2. Make a Test Print making reference to [8. 9 Test Print Mode] .
As the high voltage is supplied to the Image Corona during the Test Print, check the voltage
with the multi-meter.
Standard value of the output voltage to the Image Corona is 1.30 +/-0.05V.
CP11
multimeter
(DC)
CPCOM
