126 - 145 Platen Data
BUD No.126 to 145 are a memory for the current performance of reading white level.
There are 2 reference points;
- black level reading on Shading Chart
- white level reading on Platen Roller
The higher value gets lighter.
BUD No. Name Setting
Range
126 Platen Data 1 0 to 1024
current black level on CIS 1 (with Shading chart)
127 Platen Data 2
current black level on CIS 2 (with Shading chart)
128 Platen Data 3
current black level on CIS 3 (with Shading chart)
129 Platen Data 4
current black level on CIS 4 (with Shading chart)
130 Platen Data 5
current black level on CIS 5 (with Shading chart)
131 Platen Data R1 (Reserved)
current white level on CIS 1 in R (with Platen)
132 Platen Data R2 (Reserved)
current white level on CIS 2 in R (with Platen)
133 Platen Data R3 (Reserved)
current white level on CIS 3 in R (with Platen)
134 Platen Data R4 (Reserved)
current white level on CIS 4 in R (with Platen)
135 Platen Data R5 (Reserved)
current white level on CIS 5 in R (with Platen)
136 Platen Data G1
current white level on CIS 1 in G (with Platen)
137 Platen Data G2
current white level on CIS 2 in G (with Platen)
138 Platen Data G3
current white level on CIS 3 in G (with Platen)
139 Platen Data G4
current white level on CIS 4 in G (with Platen)
140 Platen Data G5
current white level on CIS 5 in G (with Platen)
141 Platen Data B1 (Reserved)
current white level on CIS 1 in B (with Platen)
142 Platen Data B2 (Reserved)
current white level on CIS 2 in B (with Platen)
143 Platen Data B3 (Reserved)
current white level on CIS 3 in B (with Platen)
144 Platen Data B4 (Reserved)
current white level on CIS 4 in B (with Platen)
145 Platen Data B5 (Reserved)
current white level on CIS 5 in B (with Platen)
NOTE
Shading will overwrite BUD No.126 to 145. No manual input is recommended.
