8-29
8. 5. 2 Device List
Signal
Code
Signal Name Target item
00 MAIN-TRG Main Motor
01 --- Reserved
02 --- Reserved
03 --- Reserved
04 TONER-M Toner Supply Motor
05 --- Reserved
06 R1FD-CL Roll 1 Feed Clutch
07 --- Reserved
08 --- Reserved
09 --- Reserved
10 FEED-CL Feed Clutch
11 REG.-CL Registration Clutch
12 HV-IM Image Corona
13 HV-TR Transfer Corona
14 HV-AC Separation Corona
15 BIAS-TRG Developer Bias
16 BIAS-SW Positive/Negative selection of Developer Bias
17 CLEANTRG Cleaning Roller Bias
18 CLEAN-SW Positive/Negative selection of Cleaning Roller Voltage
19 --- Reserved
20 --- Reserved
21 HEAT1 Fuser Lamp 1
22 HEAT-RY Fuser Relay
23 H BLW(L) Fuser Blower (Low speed)
24 H BLW(H) Fuser Blower (High speed)
25 EXT FAN Exit Blower
26 COUNT Reserved
27 M5_CUTL Cutter Motor (blade moves to left)
28 M5_CUTR Cutter Motor (blade moves to right)
29 POWER-SW Main Switch
30 ER1 Eraser Lamp
31 --- Reserved
32 GUIDE CL Guide Clutch
33 CSET-MTRG Paper Tray Motor
34 PICK-SL Pickup Solenoid
35 CFEED CL Paper Tray Clutch
36 LED HEAD LED Head (all the 3 units, in 3 seconds)
