KIP 700m - 8. 9. 2 Built-in Test Pattern; 8. 10 Factory Adjustment Mode

K117sm8e8
8-107
8. 9. 2 Built-in Test Pattern
Image may vary by Side Code.
example:
Pattern #4, Size Code 0: white image
Pattern #4, Size Code 1: black image
Pattern #5, Size Code 0: huge lattice
Pattern #5, Size Code 1, 2, 3…: smaller lattice
Some image patterns are factory-used only.
8. 10 Factory Adjustment Mode
This mode is mainly used at factory for adjustment and product operation test.
NOTE
Factory Adjustment Mode is not available in Service Mode. Factory Use Only.
Pattern No.1
Pattern No.2
Pattern No.3
Pattern No.4
Pattern No.5
Pattern No.6
Pattern No.7
Pattern No.8
Pattern No.9
Side Code 3
