KIP 700m - 7. 3. 2. 4 Some image is lost at the boundary of Image Blocks; 7. 3. 2. 5 Vertical image gap between Image Blocks; 7. 3. 2. 6 Image quality is not good; 7. 3. 2. 7 Density is different between left and right

K117sm7e2
7-38
7. 3. 2. 4 Some image is lost at the boundary of Image Blocks
Cause Checking
order
Checking Result Treatment
Calibration 1 Can you fix the problem if you make
Position?
(Refer to [8.13.4.3 Position].)
(Old Scanner)
(Refer to [8.14.6.2 Stitching].)
(New Scanner)
Yes OK
7. 3. 2. 5 Vertical image gap between Image Blocks
Cause Checking
order
Checking Result Treatment
Calibration 1 Can you fix the problem if you make
Position?
(Refer to [8.13.4.3 Position].)
(Old Scanner)
(Refer to [8.14.6.2 Stitching].)
(New Scanner)
Yes OK
7. 3. 2. 6 Image quality is not good
Cause Checking
order
Checking Result Treatment
Scan Glass 1 Is there any dirt or damage on the Scan
Glass?
Yes Clean / replace it.
Resolution 2 Is the resolution setting proper? No Adjust it properly.
7. 3. 2. 7 Density is different between left and right
Cause Checking
order
Checking Result Treatment
Calibration 1 Can you fix the problem if you make
Shading (Calibration)?
(Refer to [8.13.4.1 Shading].)
(Old Scanner)
(Refer to [8.14.6.1 Shading].)
(New Scanner)
Yes OK
Black Brightness
Correct
2 Can you fix the problem if you make
Black Brightness Correct?
(Refer to [8.14.6.3 Black Brightness
Correct ] .)
(New Scanner Only)
Yes OK
