KIP 700m - 56 - 59 CIS Sub; 60 Digital Gain; 61 Platen Samp Time; 62 - 65 CIS Detail

K117sm8eE
8-195
56 - 59 CIS Sub
BUD No.56 to 59 are a parameter for pixel shift in sub scanning direction. (vertical = top/bottom)
Increasing the value moves the concerning CIS block image to the bottom in 1 pixel. CIS 3 (center)
is the reference.
Be noted that Stitching Adjustment will calibrate the possible best values for No.56 to 59.
BUD No. Name Setting
Range
Step of
increment
56 cis1 Sub 50 to 150 1 pixel
block image vertical shift of CIS 1
57 cis2 Sub
block image vertical shift of CIS 2
58 cis4 Sub
block image vertical shift of CIS 4
59 cis5 Sub
block image vertical shift of CIS 5
60 Digital Gain
BUD No.60 is a fixed setting for developers.
setting value Contents
0 Correction for transparent documents activated
according to No.181-200
1 Correction for transparent documents activated
based on pre-programmed (fixed) parameters.
2 not supported.
61 Platen Samp Time
BUD No.61 is a reserved parameter for “white level compensation”.
62 - 65 CIS Detail
BUD No.62 to 65 are a reserved parameter for Stitching Adjustment.
NOTE
Stitch Adjustment will overwrite BUD No.56 to 59.
NOTE
Fixed value. Keep the value unchanged.
NOTE
Reserved. Keep the value unchanged.
NOTE
Reserved. Keep the value unchanged.
