K117sm2e1
Chapter 2
Installation
Page
2. 1 Unpack 2- 1
2. 2 Installation Requirements 2- 3
2. 3 Accessory List 2- 4
2. 4 Stand Setup 2- 5
2. 5 Scanner Part 2- 6
2. 6 Roll Deck 2- 6
2. 7 Inner Feeder Unit Setup 2- 7
2. 8 LED Head Assy Setup 2- 8
2. 9 Developer Unit Setup 2-10
2. 10 Process Unit Setup 2-11
2. 11 Installing Accessory 2-13
2. 12 Supplying Initial Toner 2-13
2. 13 Creating Backup 2-15
2. 14 Stitching Adjustment (for New Scanner) 2-20
2. 14. 1 Launching K129 Diag 2-20
2. 14. 2 Stitching Adjustment 2-24
2. 14. 3 Creating Backup Data 2-40
The machine had passed our strict inspection after careful adjustment in the factory, and
then it was packaged and shipped. Installation is an important work to make the machine
work at customer’s site as same as it has passed our strict inspection before shipment.
A service engineer has to understand machine’s function very well. Install the machine in a
good environmental place in a correct way, and then check that it works perfectly.
