5. 1. 4 Developer Unit
5. 1. 4. 1 Replacement Procedure
1. Remove 2 Bind Head Screws (M4x6) (1) to remove Cover 31 (2).
1
2
Reference
You can check what to do in step by step with using “Developer Replacement Wizard” on the
touch screen. For better understanding, first please read [5.1.4.1 Replacement Procedure]
before running the wizard.
Example of use of the wizard is shown on [5.1.4.2 Using Wizard].
