20 - 34 Strobe
BUD No.20 to 34 are a parameter for CIS’s illuminating time in color scanning.
Increasing the value gets scanned images lighter.
Be noted that Shading will calibrate the possible best values for No.20 to 34.
BUD No. Name Setting
Range
20 Strobe 1 (R) 1 to 255
CIS 1 light source R illuminating time for color scanning
21 Strobe 1 (G)
CIS 1 light source G illuminating time for color scanning
22 Strobe 1 (B)
CIS 1 light source B illuminating time for color scanning
23 Strobe 2 (R)
CIS 2 light source R illuminating time for color scanning
24 Strobe 2 (G)
CIS 2 light source G illuminating time for color scanning
25 Strobe 2 (B)
CIS 2 light source B illuminating time for color scanning
26 Strobe 3 (R)
CIS 3 light source R illuminating time for color scanning
27 Strobe 3 (G)
CIS 3 light source G illuminating time for color scanning
28 Strobe 3 (B)
CIS 3 light source B illuminating time for color scanning
29 Strobe 4 (R)
CIS 4 light source R illuminating time for color scanning
30 Strobe 4 (G)
CIS 4 light source G illuminating time for color scanning
31 Strobe 4 (B)
CIS 4 light source B illuminating time for color scanning
32 Strobe 5 (R)
CIS 5 light source R illuminating time for color scanning
33 Strobe 5 (G)
CIS 5 light source G illuminating time for color scanning
34 Strobe 5 (B)
CIS 5 light source B illuminating time for color scanning
35 - 46 Offset Block, Gain Block
BUD No.35 to 46 are a parameter for “black level compensation”.
Be noted that Shading will calibrate the possible best values for No.35 to 46.
NOTE
Shading will overwrite BUD No.20 to 34.
NOTE
Shading will overwrite here. No manual input is recommended.
