KIP 700m - 7. 1. 2. 3 E-0003 Fuser Error; 7. 1. 2. 4 E-0005 Fuse Error

K117sm7e1
7-12
7. 1. 2. 3 E-0003 Fuser Error
E-0003: Fuser Temperature Abnormal Fall Error
Cause Checking
order
Checking Result Treatment
Error clearance 1 Have you cleared the fuser error in the
Special Operation Mode?
Yes Wait until the Fuser Unit is
enough cooled down.
Then select the Special
Operation Mode and clear
the concerning error.
Wires 2 Are wires among Lamp (H1), Solid State
Relay (SSR1) and Thermistors (TH1 &
TH2) connected properly?
No Connect them properly.
Thermistors
(TH1 & TH2)
3 Select the Information Mode, and then
check the temperature of fuser detected
by Thermistors (TH1 & TH2).
Item No. : 00 (Fuser temperature 1)
01 (Fuser temperature 2)
Is each temperature normal?
No Replace the concerning
Thermistor.
7. 1. 2. 4 E-0005 Fuse Error
Cause Checking
order
Checking Result Treatment
Wires 1 Is the wire between the Fuse and
PW11720 PCB connected properly?
No Connect it properly.
DC Power Supply
(DCP1)
or Fuse
2 Confirm that the machine is turned OFF,
and then check the Fuse.
Is it OK?
No Replace the Fuse with a new
one.
3 Confirm that the machine is turned on,
and then check the voltage of the orange
line (J220-5).
Is it 24V?
No Replace the DC Power
Supply if there is no problem
with the wires.
