KIP 700m - 868 to 870 Leading Registration (Paper Tray); 871 to 873 Paper Tray Motor Speed

K117sm8e7
8-90
868 to 870 Leading Registration (Paper Tray)
To shift the start point of printing images toward the trailing edge (wider leading margin), increase
the value.
Increasing the value by 1 shifts the start point toward the trailing edge in about 0.5mm.
Item No. Setting Item Setting
range
Step of
increment
868
Leading Registration (Paper Tray) (A4 / 9”/ 8.5”)
0 to 80 0.5mm
869
Leading Registration (Paper Tray) (A3 / 18”/ 17”)
0 to 80 0.5mm
870
Leading Registration (Paper Tray) (A2 / 24”/ 22”)
0 to 80 0.5mm
871 to 873 Paper Tray Motor Speed
This will compensate the motor speed of Paper Tray (option).
Increasing the value by 1 shrinks the print image in about 0.1mm per 100mm.
Item No. Setting Item Setting
range
871
Paper Tray Motor Speed (A4 / 9”/ 8.5”)
0 to 254
872
Paper Tray Motor Speed (A3 / 18”/ 17”)
0 to 254
873
Paper Tray Motor Speed(A2 / 24”/ 22”)
0 to 254
NOTE
Reducing the value too much may result in a print jam in the exit area or a dirt image.
