K117sm1e1
1-3
1. 2 Specifications
1. 2. 1 General
Subject Specification
Model KIP 700m
Configuration Console
Power consumption
(Maximum)
1500w (US model)
1600w (Europe/Asia model)
(Including Scanner & Controller Unit)
Power consumption
(Low power mode)
13w or less (US model)
13.5w or less (Europe/Asia model)
Acoustic noise Idling Max. 51db
Printing Max. 60db
(impulse sound excluded) EN ISO 7779
Ozone Max. 0.05ppm (Measurement method under UL Standard)
Dimensions 1245mm (Width) x 833mm (Depth) x 1174mm (Height)
(including Stand)
Weight About 144kg / 318lbs (Stand excluded)
Environmental condition
for usage
Temperature: 10 to 32 degrees Centigrade / 50 to 89.6 F
Humidity: 15 to 85% RH
Interface Network Interface (10 BASE-T / 100 BASE-TX / 1000 BASE-T)
Rating input power In the US : 120V plus/minus 10%, 50/60Hz, 12A
In Europe : 220-240V plus 6% or minus 10%, 50/60Hz, 6.5A
NOTE
The above specifications are subject to change without notice.
