KIP 700m - 8. 4. 2 List of Analog Data Monitor

K117sm8e3
8-23
8. 4. 2 List of Analog Data Monitor
Data
Code
Item Unit Remarks Contents
00 Fuser Temp 1 Centigrade Calculated
Value
temperature detected by the thermistor on the
center of the Fuser Unit
01 Fuser Temp 2 Centigrade Calculated
Value
temperature detected by the thermistor on the
right of the Fuser Unit
02 LED Temp Centigrade Calculated
Value
temperature detected on LED Head (PW11755)
03 Machine Temp Centigrade Calculated
Value
temperature detected on PW11720
04 Analog. Vol.1 (Reserved)
05 Analog. Vol.2 [ V ] analog output
06 Analog. Vol.3 (Reserved)
07 Total Cut number of operation times in total for media cut
with any source / situation
08 Roll 1 Cit number of operation times for media cutting from
Roll 1
09 Others Cut number of operation times for media cutting for
trim cut
10 Total Image number of operation times in total for printing
operation with any source
11 M Image number of operation times for printing operation
on Bypass Feeder
12 R1 Image number of operation times for printing operation
on Roll 1
13 Cassette Image number of operation times for printing operation
on Paper Tray
14 R1F Clutch number of operation times of Roll 1 Clutch
15 Feed Clutch number of operation times of Feed Clutch
16 Reg. Clutch number of operation times of Registration Clutch
17 Guide Clutch number of operation times of Guide Clutch
18 Cassette Clutch number of operation times of Paper Tray Clutch
19 Pickup Solenoid number of operation times of Pickup Solenoid
20 (Reserved) - - (Reserved)
21 (Reserved) - - (Reserved)
22 Motor 1 Time minute total operation time of Main Motor
23 Motor 2 Time minute (Reserved)
24 LED ON Time minute total lighting-up time of LED Head
25 Density V0 development
use
26 Density V1 development
use
27 Density Vr development
use
28 Density DA1 development
use
29 Bias 2 Vol Hex Developer Bias output
30 Bias 3 Vol Hex Regulation Bias output
31 Image Ratio % Coverage Rate (dot ratio) of the latest sheet
32 FPGA Version
