KIP 700m - 018 Cut Length 3 (Compensation of the length of a long print)

K117sm8e6
8-51
018 Cut Length 3 (Compensation of the length of a long print)
When you make a long print, the actual print length may become shorter than expected because
the paper is likely to shrink. It is possible in this mode to compensate the print length manually.
The length of long print is not compensated directly, but it is indirectly compensated by correcting
the length of A1 print.
If you increase the setting value by “+1”, the length of A1 print becomes 0.1mm longer per 10mm.
Setting Range Step of increment
1 to 999 0.1mm
[Example of adjustment]
1. Supposing the actual length of a long print is shorter than expected.
Expected length Actual length
Actual length is shorter than expected.
0
100
50
A B C
0
100
50
A B C
NOTE
It is necessary to finish the adjustment of Cut Length 1 (No.016) before starting the
adjustment in this Cut Length 3 (No.018).
