KIP 700m - 5. 1. 3 Filters

K117sm5e2
5-8
5. 1. 3 Filters
1. Remove 3 Bind Head Screws (M4x6) (1) on each side.
2. Press the blue lever (2) on both sides to open the Upper Unit.
3. Slightly lift Side Cover R (3) / Side Cover L (4) up to the arrow direction to remove then from the
machine.
2
2
4
3
1
1
1
1
3
