KIP 700m - 8. 14. 7. 2 Signal List

K117sm8eE
8-243
8. 14. 7. 2 Signal List
Name Target Symbol default To change status,
Size Sensor 1 size detection:
A4 landscape, A3, 11”, 12”
S_PH2 red Put a sheet over the sensor.
Size Sensor 2 size detection:
A2, 17”, 18”
S_PH3 red
Size Sensor 3 size detection:
A1, 22”, 24”
S_PH4 red
Size Sensor 4 size detection:
A0, 30”
S_PH5 red
Size Sensor 5 size detection:
34”, 36”
S_PH6 red
Document
Sensor Front
detects document insertion
detects document jam
size detection:
A4 portrait
S_PH1 red
Document
Sensor Rear
document jam S_PH7 red
Cover Open Upper Unit open S_PH8 black Open / close the Upper Unit.
Feed Roller
Sensor
Feed Roller rotation S_PH9 (depends) Gently rotate the Feed Roller
toward the rear.
Power ON
Signal
(reserved) black
Scan Start
Switch
(reserved) black
Emergency Stop
Switch
Stops document feeding S_MS1 black Press [Emergency Stop]
button.
Document Eject
Switch
(reserved) black
