759 Regulation Bias Increment for Adjustment Level 2 and after
It is possible to change the amount (increment) of Regulation Bias on Auto Adjustment.
A specified increment of Regulation Bias will be applied at switching to Auto Adjustment Level 2
and Level 3.
The default voltage value of the increment is about 40V (corresponding to “80” in the setting value)
for switching to Auto Adjustment Level 2 and 3.
If you increase the setting value by “+1”, the increment of Regulation Bias Adjustment becomes
about 0.5V higher.
Setting Range Step of increment
0 to 200 0.5V
760, 761 Regulation Bias Limit
These items specify the minimum / maximum Regulation Bias.
Item
No.
Setting Item Setting
range
760 Regulation Bias Limit (minimum, absolute value) 0 to 399
761 Regulation Bias Limit (maximum, absolute value) 400 to 800
762 to 767 Developer Reference Bias
It is possible to define the 6 values for Developer Reference Bias analog voltage.
Item
No.
Setting Item Setting
range
762 Developer Reference Bias 1 000 to 9FE
763 Developer Reference Bias 2 000 to 9FE
764 Developer Reference Bias 3 000 to 9FE
765 Developer Reference Bias 4 000 to 9FE
766 Developer Reference Bias 5 000 to 9FE
767 Developer Reference Bias 6 000 to 9FE
Developer Reference Bias are used only to find out the possible best output voltage of Developer
Bias for the target density.
NOTE
This setting has been factory-adjusted. Keep the value unchanged.
NOTE
This setting has been factory-adjusted. Keep the value unchanged.
NOTE
This setting does not function. Keep the value unchanged.
