KIP 700m - 4. 3. 4 AC Component to Separation Corona

K117sm4e3
4-22
4. 3. 4 AC Component to Separation Corona
The standard value of the AC Component outputted from the HV Power Supply PCB to the
Separation Corona is 5.00 +/-0.05V.
Check and adjust the AC Component in the following way.
1. Connect the “+” cable of the multi-meter to the “CP31” pin on the HV Power Supply PCB
(EUK1MGA60HA).
Also connect the “-” one to the “CPCOM” pin.
And then, select the DC volt range on the multi-meter.
2. Make a Test Print making reference to [8. 9 Test Print Mode].
As the high voltage is supplied to the Image Corona during the Test Print, check the voltage
with the multi-meter.
Standard value of the AC Component to the Separation Corona is 5.00 +/-0.05V.
CP31
CPCOM
multimeter
(DC)
