K117sm4e3
4-21
2. Select the Test Print Mode, and make a test print using each type of paper (plain
paper, tracing paper & Film) making reference to [8. 9 Test Print Mode].
As the high voltage is supplied to the Transfer Corona during the Test Print, check the voltage
with the multi-meter.
Standard values of the output voltages to the Transfer Corona are:
Plain paper 1.00 +/-0.05V
Tracing paper 1.00 +/-0.05V
Film 1.00 +/-0.05V
3. Adjust the output voltage if it does not satisfy the above specifications.
Select the Adjustment Mode, select each of following Sub Mode Numbers, and change the
setting value so that the output voltage satisfies the above specifications.
Refer to [8.6.3 029 to 034 Transfer Voltage] for the detail.
Sub Mode No. Contents
029 Transfer Voltage (Plain paper)
030 Transfer Voltage (Tracing paper)
031 Transfer Voltage (Film)
032 Transfer Voltage (Plain paper : Special)
033 Transfer Voltage (Tracing paper : Special)
034 Transfer Voltage (Film : Special)
To Next Page
