7. 1. 2 Countermeasures - Call Service Errors
The followings are the names of Service Call Errors and the conditions that those errors occur.
Error Code Error Indication Conditions
E-0000 Fuser Temperature Rising Error Fuser Temperature does not reach 50
o
C
within 120 seconds after turning on.
E-0001 Fuser Over Temperature Error Fuser Temperature reaches over 200
o
C.
E-0002 Fuser Low Temperature Error 1. Fuser Temperature at the time of
turning on was 50 to 100
o
C, but it
does not rise up to 120
o
C within 150
seconds after that.
2. Fuser Temperature at the time of
turning on was higher than 100
o
C, but
it does not rise up to the setting
temperature within 270 seconds after
that.
E-0003 Fuser Temperature Abnormal Fall
Error
The difference of temperature between
center and side of fuser becomes 50
o
C or
more.
E-0004 Fuser Temperature Abnormal Fall
Error
The Lamp of fuser lights (Signal HEAT1
is “H”) to heat up the Fuser Roller in the
ready condition, but even 1
o
C of
temperature rise can not be
accomplished within 30 seconds.
E-0005 Fuse Error Fuse (F1) is broken.
E-0010 Main Motor Error The Main Motor Output Detection Signal
(MAINM_LD) continues to be “H” for 3
seconds or longer when the Main Motor is
rotating.
E-0013 Paper Tray Motor Error The Paper Tray Motor Output Detection
Signal (CSETM_LD) continues to be “H”
for 3 seconds or longer when the Paper
Tray Motor is rotating.
E-0020 Counter Error The Counter Connection Detection Signal
(COUNT_OPN) continues to be “L” for 1
second or longer after turning on.
E-0031 Image Corona Output Error The Image Corona Output Detection
Signal (IM_LD) continues to be “L” for 1
second or longer when the Image Corona
is ON.
E-0032 Separation Corona Output Error The Separation Corona Output Detection
Signal (AC_LD) continues to be “L” for 1
second or longer when the Separation
Corona is ON.
E-0033 Transfer Corona Output Error The Transfer Corona Output Detection
Signal (TR_LD) continues to be “L” for 1
second or longer when the Transfer
Corona is ON.
