8-17
8. 4 Information Mode
It is possible to monitor the analog voltage input sent by devices (such as Thermistor) to DC
Controller PCB. It is also possible to monitor the current Fuser temperature which is calculated
from the input voltage.
Information Mode includes the list of the latest 100 jam / service call error records.
Information Home screen
Name Function
1 No.00 - 32 Switches to Monitor screen
2 No.33 Switches to Jam History screen
3 No.34 Switches to Error History screen
4 Contents Explains the contents of the item
5 Back Returns to Service Mode Home
The number shown in the second / third / last tab may vary by KIP printer model or printer firmware version.
5
1 2 3
4
