47 - 51 Luminance
BUD No.20 to 34 are a parameter for CIS’s light intensity in mono scanning.
Increasing the value gets scanned images lighter.
Be noted that Shading will calibrate the possible best values for No.47 to 51.
BUD No. Name Setting
Range
47 Luminance 1 1 to 255
CIS 1 light intensity for mono scanning
48 Luminance 2
CIS 2 light intensity for mono scanning
49 Luminance 3
CIS 3 light intensity for mono scanning
50 Luminance 4
CIS 4 light intensity for mono scanning
51 Luminance 5
CIS 5 light intensity for mono scanning
52 - 55 CIS Main
BUD No.52 to 55 are a parameter for pixel shift in main scanning direction. (horizontal = left/right)
Increasing the value moves the concerning CIS block image (and the later blocks together) to the
right in 1 pixel. CIS 1 (far left) is the reference.
Be noted that Stitching Adjustment will calibrate the possible best values for No.52 to 55.
BUD No. Name Setting
Range
Step of
increment
52 cis1/cis2 Main 0 to 200 1 pixel
block image horizontal shift of CIS 2 (and CIS 3/4/5 together)
53 cis2/cis3 Main
block image horizontal shift of CIS 3 (and CIS 4/5 together)
54 cis3/cis4 Main
block image horizontal shift of CIS 4 (and CIS 5 together)
55 cis4/cis5 Main
block image horizontal shift of CIS 5
NOTE
Shading will overwrite BUD No.47 to 51.
NOTE
Stitch Adjustment will overwrite BUD No.52 to 55.
