789 to 800 Transfer Corona OFF Timing (Roll)
It is possible to adjust the timing that the Transfer Corona stops discharging during the print cycle.
This can be configured by every media type / width.
If you increase the setting value by “+1”, the timing to stop discharging is 1mm delayed.
Setting Range Step of increment
0 to 100 1mm
Plain
Paper
Tracing
Paper
Film
A3, 11”, 12” No.789 No.790 No.791
A2, 15”, 17”, 18” No.792 No.793 No.794
A1, 22”, 24” No.795 No.796 No.797
A0, B1, 30”, 34”, 36” No.798 No.799 No.800
NOTE
You may lose some trailing image as the following example if you decrease the setting value
too much, because the Transfer Corona stops discharging too early.
Normal Setting value is increased too much.
Transfer Corona stops
discharging at this point.
