K117sm8e4
8-37
8. 6. 2 Setting Item List
Default Values may differ by individual machine. See the backup ini file or the service sheet attached
inside the machine. All items grayed are not generally for field technician use
Item Setting Item Unit setting range Default (sample)
No. US EU/Asia
000 Leading Registration (Roll paper) 1mm 0 to 40 27 27
001 Leading Registration (Cut sheet paper) 1mm 0 to 40 26 26
002 Trailing Margin (Roll paper) 1mm 0 to 40 11 11
003 Trailing Margin (Cut sheet paper) 1mm 0 to 40 12 12
004 Side Margin (Left and right) 1mm 0 to 20 3 3
005 Side Registration (Cut sheet paper) 0.1mm 0 to 100 50 50
006 Side Registration (Roll paper) 0.1mm 0 to 100 50 50
007 Reserved
008 LED Strobe Time for Main Pixel (Block A) 1 microsecond 0 to 10 7 7
009 LED Strobe Time for Main Pixel (Block B) 1 microsecond 0 to 10 7 7
010 LED Strobe Time for Main Pixel (Block C) 1 microsecond 0 to 10 7 7
011 LED Strobe Time for IST (Supplemental Pixel) (Block A) 1 microsecond 0 to 18 9 9
012 LED Strobe Time for IST (Supplemental Pixel) (Block B) 1 microsecond 0 to 18 9 9
013 LED Strobe Time for IST (Supplemental Pixel) (Block C) 1 microsecond 0 to 18 9 9
014 Vertical Alignment of LED Block A/B 0.5pixel 0 to 144 72 72
015 Vertical Alignment of LED Block B/C 0.5pixel 0 to 144 72 72
016 Cut Length 1 (length information provided) 1mm 0 to 100 50 50
017 Cut Length 2 (length information not provided) 1mm 0 to 100 50 50
018 Cut Length 3 (Compensation of the length of a long print) 0.1mm 1 to 999 440 440
019 Leading Margin 0.1mm 0 to 50 30 30
020 Reserved
021 Reserved
022 Developer Bias (Plain Paper) (Hex.) 000 to 4FF 161 161
023 Developer Bias (Tracing Paper) (Hex.) 000 to 4FF 161 161
024 Developer Bias (Film) (Hex.) 000 to 4FF 161 161
025 Developer Bias (Special Media/Plain Paper) (Hex.) 000 to 4FF 161 161
026 Developer Bias (Special Media/Tracing Paper) (Hex.) 000 to 4FF 161 161
027 Developer Bias (Special Media/Film) (Hex.) 000 to 4FF 161 161
028 Developer Bias compensation - 1st Drum revolution - 0 to 255 0 0
029 Transfer Voltage (Plain Paper) (Hex.) 000 to 4FF 366 366
030 Transfer Voltage (Tracing Paper) (Hex.) 000 to 4FF 28A 28A
031 Transfer Voltage (Film) (Hex.) 000 to 4FF 28A 28A
032 Transfer Voltage (Special Media/Plain Paper) (Hex.) 000 to 4FF 292 292
033 Transfer Voltage (Special Media/Tracing Paper) (Hex.) 000 to 4FF 292 292
034 Transfer Voltage (Special Media/Film) (Hex.) 000 to 4FF 292 292
035 Separation Corona ON Timing 1mm 0 to 100 50 50
036 Reserved
037 Transfer Corona ON Timing 1mm 0 to 100 50 50
038 Reserved
039 Reserved
040 Reserved
041 Reserved
042 Reserved
043 Reserved
044 Reserved
045 Fuser temperature to Start Idling 1
o
C 100 to 140 120 120
046 Warm Sleep - Fuser Temperature 1
o
C 100 to 160 100 100
047 Reserved
048 Fuser Temperature Control Range (In the print cycle) 1
o
C 1 to 6 1 1
049 Fuser Temperature Control Range (Stand by) 1
o
C 1 to 6 2 2
050 Reaction Time of Toner Supply Motor 1 Second 1 to 30 3 3
051 Toner Supply Motor Time 1 Second 1 to 75 25 25
052 Dot Enhancement Level (Dither ) - 0 to 3 1 1
053 Reserved
054 Reserved
055 Metric or Inch - 0 to 1 1 0
056 Language - 0 to 1 1 1
057 Reserved
058 Reserved
059 Count Unit (Counter A = Print Count) - 0 to 6 5 ---
060 Maximum Length - 0 to 1 0 0
061 Reserved
062 Reserved
063 Cut length 5 (Compensation for Tracing Paper) - 0 to 200 100 100
064 Cut length 6 (Compensation for Film) - 0 to 200 100 100
065 Drum Reverse Time 1 millisecond 10 to 100 70 70
066
to
309
Reserved -
310 Main Motor Speed (Plain paper) 0.04mm/s 0 to 80 40 40
