22. With pressing down the Toner Bottle (25), slide the green lever (28) to the arrow direction until
it stops. When it stops, wait 10 seconds as it is.
Gently tap the top of the Toner Bottle several times.
23. Slide the green lever (28) to the original position. Remove the Toner Bottle.
NOTE
It is impossible to remove the Toner Bottle unless the lever (5) completely moves to the
original position.
Do not attempt to remove the Toner Bottle by force if the lever is not at the original position.
Doing so may damage toner supply system.
from right
NOTE
Gently press down the Toner Bottle. Pressing too much makes the lever (28) much heavier.
28
25
28
from right
To Next Page
