KIP 700m - Page 179

K117sm5e5
5-57
1. On both sides, pull the levers (1) to unlock the Scanner Unit. Open the Scanner Unit.
2. On a CIS to be replaced, remove 2 small screws (2) with a sharp screwdriver.
1
1
NOTE (cont.)
3. Loosen 1 screw (3) and remove 1 screw (4) to
remove the plastic cover (5).
4
3
5
2
