KIP 700m - Page 277

KIP 700m - PM Schedule (Parts Method)
r1
-The Dealer may choose to use the PM KIT method or PM Parts method when performing PM service. Please use this form when using the PM Parts Method.
-Please keep this form with the KIP 700m ; Please perform PMs as scheduled
-As the PM comes due and items replaced or cleaned, please denote with an "X" in the Confirmation box. Please note nomenclature below.
Part / Description Qty Part Number Linear Meters X 1000
Code
6
Complete
12
Complete
18
Complete
24
Complete
30
Complete
36
Complete
42
Complete
Document Glass ( scanner ) # C C C C C C C
Document Rollers ( scanner ) # C C C C C C C
Photoreceptor 1 Z178080290 R
Main Charge Wire 1 Z175101420 # R R R R R R R
Transfer Wire 1 4205100240 # R R R R R R R
Separation Wire 1 4205100240 # R R R R R R R
Grid Screen # C C C
LED Head # C C C C C C C
Developer Space Discs # C C C
Lube Gears L L L
Developer Maintenance Kit 1 Z178080271 R R R
Roll Compartment & Interior @ C C C C C C C
Knife Z171101030 @ C
Filters - Kit 1 Z178070010 @ R R R R R
R R
Lube Gears L L L
Fuser Fingers C C C C C C C
Fuser Roller C C C
Pressure Roller C C C
Thermostat C C C
Thermistor C C C
Exterior Covers / GUI # C C C C C C C
# = Clean with glass cleaner and wipe dry
@ = Clean with vacuum
Subject to change without notice
Actual intervals may vary due to customer requirements / installation location Page 1
L = Lubricate C = Clean
I = Inspect
R = Replace
A = Adjust position
