KIP Service Software Tree Diagram of screen menu hierarchy
Login screen
Service Mode Home
(Signal Status Mode) Signal Status Monitor screen
(Information Mode) Information List screen
Data Monitor
Jam History
Error History
(Operation Check Mode) Operation Check screen
(Adjustment Mode) Adjustment Menu screen
Setting Configuration
Setting Backup/Restore
View Table
(Jam/Error Mask Mode) Mask Target screen
Jam Mask
Error Mask
(Test Print Mode) Basic Setting
Option
(Special Operation Mode) Operation Target screen
Confirmation Dialog
Toner Setup
Fuser Error Clear
Jam/Error History Clear
Bias Adjustment Reset
(Send Firmware Mode) Firmware screen
Running Mode, Factory Adjustment Mode (not available)
Wizard
LED Head Confirmation
Cut Length Confirmation
Image Position Confirmation
Media Feed Sensor Check
Developer replacement Procedure (Bias Reset included)
Serial Port Setting
