8-147
8. The scan image of Scanner Adjustment Chart is indicated in the screen of KIP Scanner Utility.
Scan image of the chart
9. Indicate the enlarged image of “a point” on the screen, which was the measuring point at the
former step “1”.
You can enlarge the scan image by dragging with the right button of mouse.
Press the F2 Key when you would like to go back to the reduced image.
Reference
