8-156
11. Enlarge the top center area by right dragging.
Reference
There is a gap between the leading edge of the scan image and the leading edge of the
chart at this time. This band area shows that both of the edges do not match together.
The gap will be removed after the completion of Position adjustment for the leading edge.
Leading edge
of original
Leading edge
of image
gap (band)
reading start here
original LE
reading start here original LE
