9-38
4 How to Remove
1. Remove the loaded sheets. Retract the table if extended.
2. With holding the gray levers (1) on both sides, pull Table Assy (2).
3. Disconnect the harness (3) from Connector Bracket.
4. Remove 1 screw (4) on each side to unfix the release levers.
1
2
3
1
4 44
