215916 91 Revision A
Figure 3.99: Brightness and Volume
1. Navigate to the SETTINGS menu with soft key 5 and the
Harvest Performance Tracker (HPT) scroll knob. For
instructions, refer to 3.17.2 Navigating Harvest
Performance Tracker Display, page 81 if required.
2. Scroll to SCREEN icon (A) and select it.
3. Scroll to BRIGHTNESS AND VOLUME icon (B), and select it
to open the adjustment window.
Figure 3.100: Brightness and Volume
4. Scroll through the following four brightness modes, and
select the mode that requires adjustment:
• DAY mode (A) (default setting is 70%)
• NIGHT mode (B) (default setting is 20%)
• KEYPAD DAY mode (C) (default setting is 70%)
• KEYPAD NIGHT mode (D) (default setting is 20%)
5. Adjust the selected value by scrolling and previewing the
brightness as you scroll.
Setting Alarm Volume
The volume control adjusts the audible alarms. It is depicted with a 10-segment bar graph and is adjustable down to 10%.
The default volume is factory-set to 50%.
Adjust the volume as follows:
Figure 3.101: Main Menu
1. Navigate to SETUP Menu (C) with soft key 5 (A) and HPT
scroll knob (B). For instructions, refer to 3.17.2 Navigating
Harvest Performance Tracker Display, page 81 if required.
OPERATOR’S STATION
