6.2 Header Operation
Several kits are available which can augment the capabilities of the header attached to the windrower, or which allow the
windrower to be used with different types of headers.
6.2.1 Conversion Kit for Disc Ready to Disc, Auger, and Draper Ready
Used to convert a M1240 from Disc Ready to Disc, Draper, and Auger ready.
MD #B5999
Instruction MD #147822 is included in the bundle.
6.2.2 Booster Spring Kit – External
This kit increases the float capacity of the windrower. Install this kit on windrowers paired with headers which weigh more
than 2812 kg (6200 lb.).
MD #B6047 – Booster Spring kit (external) includes two springs (one for each side) and mounting brackets. Kit instruction
MD #147825 is included in the bundle.
There is also a Double Booster Spring kit (MD #B6106) that is used together with the Booster Spring kit (external) to add on
a second booster spring. For more information, refer to 6.2.3 Double Booster Spring Kit – External, page 483.
Table 6.1 Available Float Spring Kits for Different Header Types and Configurations
Header Type
Description
Header Configuration
Additional
Float Spring Kits
D130XL
9.1 m (30 ft.)
single reel,
double knife, timed
Transport
—
D130XL
9.1 m (30 ft.)
single reel,
double knife, timed
Transport
Upper Cross Auger
Vertical Knives
MD #B6047
D135XL
10.8 m (35 ft.)
single reel,
double knife, untimed
Base
—
D135XL
10.8 m (35 ft.)
single reel,
double knife, untimed
Transport
MD #B6047
D135XL
10.8 m (35 ft.)
single reel,
double knife, untimed
Transport
Upper Cross Auger
Vertical Knives
MD #B6047
D135XL
10.8 m (35 ft.)
double reel,
double knife, untimed
Base
—
D135XL
10.8 m (35 ft.)
double reel,
double knife, untimed
Transport
MD #B6047
D135XL
10.8 m (35 ft.)
double reel,
double knife, untimed
Transport
Upper Cross Auger
Vertical Knives
MD #B6047
D140XL
12.2 m (40 ft.)
double reel,
double knife, untimed
Base
—
