Oval EL4101 - ⑮ Density Calculation - Reference Temperature Conversion Factor of Density (THERMAL EXPAN. (Β)); ⑯ Density Calculation - Density of Carrier Fluid (CARRIER DENS.); ⑰ Density Calculation - Density of Target Fluid (TARGET DENS.)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＴＨＥＲＭＡＬ ＥＸＰＡＮ．（β）  
         ＋２．４００００ Ｅ−４
                     
                     
                     
＋２．４００００  
       Ｅ−４
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＣＡＲＲＩＥＲ ＤＥＮＳ．      
         ＋７．８００００ Ｅ＋２
                     
                     
                     
＋７．８００００  
       Ｅ＋２
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＴＡＲＧＥＴ ＤＥＮＳ．       
         ＋１．６５０００ Ｅ＋３
                     
                     
                     
＋１．６５０００  
       Ｅ＋３
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
E-880TM-3-E
110
Density calculation setup submenu screen p. 103
⑮ Density calculation - reference temperature conversion factor of density
(THERMAL EXPAN. (β))
The reference temperature conversion factor of density for temperature correction is set up here.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ The measurement unit to be set here is “g/ml/°C”. Make sure of the unit
before you set up.
Density calculation setup submenu screen p. 103
⑯ Density calculation - density of carrier fluid (CARRIER DENS.)
The carrier fluid density for calculation of solids content in terms of weight concentration is set up here.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 105) is used.
Make sure of the unit before you set up.
Density calculation setup submenu screen p. 103
⑰ Density calculation - density of target fluid (TARGET DENS.)
The target fluid density for calculation of solids content in terms of weight concentration is set up here.
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 105) is used.
Make sure of the unit before you set up.
