Oval EL4101 - ⑥ Density Calculation - over Fallback Level Setup (over FALLBACK); ⑦ Density Calculation - Reference Temperature Setup (REF. TEMP.); ⑧ Density Calculation - Density with Air (AIR DENS.)

                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＯＶＥＲ ＦＡＬＬＢＡＣＫ     
         ＋１．２００００ Ｅ＋３
                     
                     
                     
＋１．２００００  
       Ｅ＋３
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＡＩＲ ＤＥＮＳ．          
         ＋１．２００００ Ｅ＋０
                     
                     
                     
＋１．２００００  
       Ｅ＋０
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ 
                     
／                    
−−−−−＜ＳＥＴ ＭＯＤＥ＞−−−−−−

ＤＥＮＳＩＴＹ ＰＡＲＡＭＥＴＥＲ   


ＲＥＦ． ＴＥＭＰ．         
         ＋２．０００００ Ｅ＋１
                     
                     
                     
＋２．０００００  
       Ｅ＋１
−−−−−−−＜ＩＮＰＵＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜ＣＬＥＲ｜ＥＮＴＲ
E-880TM-3-E
11
⑥ Density calculation - over fallback level setup (OVER FALLBACK)
The over fallback level with respect to the corrected density is set up here.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 114) is used.
Make sure of the unit before you set up.
⑦ Density calculation - reference temperature setup (REF. TEMP.)
The reference temperature for temperature compensation is set up here.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ For the unit to be set here, the unit set at the temperature unit setup
(① Temperature input unit setup (UNIT) on page 51) is used. Make sure of
the unit before you set up.
⑧ Density calculation - density with air (AIR DENS.)
The air density during calibration is set up here for density calculation.
Density calculation setup submenu screen p. 112
←Numerical value input setup
For details of numerical value input setup, see “(1) Numerical value setup screen
(INPUT)” on page 43.
※ In SYS mode density input (① Density input type setup (TYPE) on page
156), if NONE is chosen for the input type, this menu will not be shown.
※ For the unit to be set here, the unit set at the density unit setup in density
calculation (① Density calculation unit setup (UNIT) on page 114) is used.
Make sure of the unit before you set up.
