Oval EL4101 - Blend Input Setup (BLEND INPUT); Blend Input Submenu Screen; ① Blend Input Type Setup (TYPE)

                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        


ＴＹＰＥ               
                 １−５Ｖ
 １：ＮＯＮＥ              

２：４−２０ｍＡ            
 ３：１−５Ｖ              
                     
                     
                     
                     
−−−−−−＜ＳＥＬＥＣＴ＞−−−−−−−
     ｜ＣＡＮ−｜    ｜     
 ＥＸＩＴ｜ ＣＥＬ｜    ｜ＥＮＴＲ
                     
                     
−−−−−＜ＳＹＳ ＭＯＤＥ＞−−−−−−

ＢＬＥＮＤ ＩＮＰＵＴ        

・ＴＹＰＥ               
                 １−５Ｖ
                     
                     
                     
                     
                     
                     
                     
−−−−−＜ＳＵＢ  ＭＥＮＵ＞−−−−−
 ＭＡＩＮ｜    ｜    ｜     
 ＭＥＮＵ｜    ｜    ｜ＥＮＴＲ
E-880TM-3-E
1
7.4.12 Blend Input Setup (BLEND INPUT)
Input type of the blend input is set up here.
※ This setting is used only in EL4401. This item is not shown in other models.
（1）Blend input submenu screen
At the submenu, move the cursor to the desired setup item with the up and down arrow keys.
At the touch of function key “ENTR”, the screen switches to the desired setup screen.
① Blend input type setup (TEYPE) p. 165
Blend input submenu screen p. 165
To the setup screen pointed by the cursor
7.1.1 SYS mode main menu screen p. 142
① Blend input type setup (TYPE)
Input type of the blend input is set up here.
※ If you have changed the input type to NONE (constant) or to other type, do not fail to make
sure of the blend input setting in the SET mode and set up the pulse output scaling. Unless it
is so configured, the computer possibly may not perform properly.
←Input type option select setup
For details of option setup, see “(2) Option select setup screen (SELECT)” on
page 46.
